Porduct Overview

EKL8-40M Magnetic type RCBO comply with IEC61009-1 standard, rated breaking capacity 6kA, rated tripping current can reach 300mA, Position Indicator, Bi-Connect Termination on both sides, Compatible with Standard & Philip head screwdriver,35mm² Terminal Suitable for Copper as well as Aluminium Cable.

1.1 Function

Personnel and fire protection: Cable and line protection against overload and short-circuits.

1.2 Selection

I∆n ≤30 mA: additional protection in the case of direct contact.
I∆n ≤300 mA: preventative fire protection in the case of ground fault currents.

Technical parameters

Technical Data

Standard	IEC/EN61009-1
Protection	Ground fault, Overcurrent and short circuit, Over-voltage(selectable)
Type of trip	Ground fault : Electro-magnetic
Type of trip	Overload and short circuit :Thermo-magnetic
Type of protection (electric leakage)	AC,A
No.of poles	1P+N 2module , N line with disconnected
Rated currents (In)	6,10,16,20,25,32,40A
Rated sensitivity currents I△n	30,100,300mA
Residual current off-time under I△n	≤ 0.1s
Rated residual making and breaking capacity(I△m)	500A(In≤50A)
Rated voltage (Ue)	230/240V~
Rated frequency	50/60Hz
Rated breaking capacity	6,000A
Energy Limiting Class	3
Rated impulse withstandard voltage(1.2/50) Uimp	4,000V
Dielectric test voltage at Ind. Freq. for 1 min	2kV
Thermal release characteristic	(1.13-1.45) x In
Magnetic release characteristic	B:(3-5) x In, C:(5-10) x In
Electrical life	4,000 Cycles
Mechanical life	10,000 Cycles
Contact position indicator	Yes
Ground fault indicator	Yes
Protection degree	IP20
Ambient temperature	-25℃ to +40℃, Max.95% humidity
Terminal connection type	Cable/Pin-type busbar/Fork-type busbar
Max.terminal size for cable	25mm2
Max.tightening torque	2.5N.m
Installation	Mounting on 35mm DIN rail
Connection	From top and bottom

Dimensions

Circuit Diagram

Installation size

Product selection form

Breaking capacity	Poles	Rated Current（A）	B Curve
			Sensitivity
			30mA	100mA	300mA
			Type AC
6KA	1P+N	6A	EKL8-40M-1NB0630	EKL8-40M-1NB06100	EKL8-40M-1NB06300
		10A	EKL8-40M-1NB1030	EKL8-40M-1NB10100	EKL8-40M-1NB10300
		16A	EKL8-40M-1NB1630	EKL8-40M-1NB16100	EKL8-40M-1NB16300
		20A	EKL8-40M-1NB2030	EKL8-40M-1NB20100	EKL8-40M-1NB20300
		25A	EKL8-40M-1NB2530	EKL8-40M-1NB25100	EKL8-40M-1NB25300
		32A	EKL8-40M-1NB3230	EKL8-40M-1NB32100	EKL8-40M-1NB32300
		40A	EKL8-40M-1NB4030	EKL8-40M-1NB40100	EKL8-40M-1NB40300
			Type A
		6A	EKL8-40M-1NB0630A	EKL8-40M-1NB06100A	EKL8-40M-1NB06300A
		10A	EKL8-40M-1NB1030A	EKL8-40M-1NB10100A	EKL8-40M-1NB10300A
		16A	EKL8-40M-1NB1630A	EKL8-40M-1NB16100A	EKL8-40M-1NB16300A
		20A	EKL8-40M-1NB2030A	EKL8-40M-1NB20100A	EKL8-40M-1NB20300A
		25A	EKL8-40M-1NB2530A	EKL8-40M-1NB25100A	EKL8-40M-1NB25300A
		32A	EKL8-40M-1NB3230A	EKL8-40M-1NB32100A	EKL8-40M-1NB32300A
		40A	EKL8-40M-1NB4030A	EKL8-40M-1NB40100A	EKL8-40M-1NB40300A
		Rated Current (A）	C Curve
			Sensitivity
			30mA	100mA	300mA
			Type AC
		6A	EKL8-40M-1NC0630	EKL8-40M-1NC06100	EKL8-40M-1NC06300
		10A	EKL8-40M-1NC1030	EKL8-40M-1NC10100	EKL8-40M-1NC10300
		16A	EKL8-40M-1NC1630	EKL8-40M-1NC16100	EKL8-40M-1NC16300
		20A	EKL8-40M-1NC2030	EKL8-40M-1NC20100	EKL8-40M-1NC20300
		25A	EKL8-40M-1NC2530	EKL8-40M-1NC25100	EKL8-40M-1NC25300
		32A	EKL8-40M-1NC3230	EKL8-40M-1NC32100	EKL8-40M-1NC32300
		40A	EKL8-40M-1NC4030	EKL8-40M-1NC40100	EKL8-40M-1NC40300
			Type A
		6A	EKL8-40M-1NC0630A	EKL8-40M-1NC06100A	EKL8-40M-1NC06300A
		10A	EKL8-40M-1NC1030A	EKL8-40M-1NC10100A	EKL8-40M-1NC10300A
		16A	EKL8-40M-1NC1630A	EKL8-40M-1NC16100A	EKL8-40M-1NC16300A
		20A	EKL8-40M-1NC2030A	EKL8-40M-1NC20100A	EKL8-40M-1NC20300A
		25A	EKL8-40M-1NC2530A	EKL8-40M-1NC25100A	EKL8-40M-1NC25300A
		32A	EKL8-40M-1NC3230A	EKL8-40M-1NC32100A	EKL8-40M-1NC32300A
		40A	EKL8-40M-1NC4030A	EKL8-40M-1NC40100A	EKL8-40M-1NC40300A

Download Files

Porduct Overview

1.1 Function

Personnel and fire protection: Cable and line protection against overload and short-circuits.

1.2 Selection

I∆n ≤30 mA: additional protection in the case of direct contact.
I∆n ≤300 mA: preventative fire protection in the case of ground fault currents.

Technical parameters

Technical Data

Standard	IEC/EN61009-1
Protection	Ground fault, Overcurrent and short circuit, Over-voltage(selectable)
Type of trip	Ground fault : Electro-magnetic
Type of trip	Overload and short circuit :Thermo-magnetic
Type of protection (electric leakage)	AC,A
No.of poles	1P+N 2module , N line with disconnected
Rated currents (In)	6,10,16,20,25,32,40A
Rated sensitivity currents I△n	30,100,300mA
Residual current off-time under I△n	≤ 0.1s
Rated residual making and breaking capacity(I△m)	500A(In≤50A)
Rated voltage (Ue)	230/240V~
Rated frequency	50/60Hz
Rated breaking capacity	6,000A
Energy Limiting Class	3
Rated impulse withstandard voltage(1.2/50) Uimp	4,000V
Dielectric test voltage at Ind. Freq. for 1 min	2kV
Thermal release characteristic	(1.13-1.45) x In
Magnetic release characteristic	B:(3-5) x In, C:(5-10) x In
Electrical life	4,000 Cycles
Mechanical life	10,000 Cycles
Contact position indicator	Yes
Ground fault indicator	Yes
Protection degree	IP20
Ambient temperature	-25℃ to +40℃, Max.95% humidity
Terminal connection type	Cable/Pin-type busbar/Fork-type busbar
Max.terminal size for cable	25mm2
Max.tightening torque	2.5N.m
Installation	Mounting on 35mm DIN rail
Connection	From top and bottom

Dimensions

Circuit Diagram

Installation size

Product selection form

Breaking capacity	Poles	Rated Current（A）	B Curve
			Sensitivity
			30mA	100mA	300mA
			Type AC
6KA	1P+N	6A	EKL8-40M-1NB0630	EKL8-40M-1NB06100	EKL8-40M-1NB06300
		10A	EKL8-40M-1NB1030	EKL8-40M-1NB10100	EKL8-40M-1NB10300
		16A	EKL8-40M-1NB1630	EKL8-40M-1NB16100	EKL8-40M-1NB16300
		20A	EKL8-40M-1NB2030	EKL8-40M-1NB20100	EKL8-40M-1NB20300
		25A	EKL8-40M-1NB2530	EKL8-40M-1NB25100	EKL8-40M-1NB25300
		32A	EKL8-40M-1NB3230	EKL8-40M-1NB32100	EKL8-40M-1NB32300
		40A	EKL8-40M-1NB4030	EKL8-40M-1NB40100	EKL8-40M-1NB40300
			Type A
		6A	EKL8-40M-1NB0630A	EKL8-40M-1NB06100A	EKL8-40M-1NB06300A
		10A	EKL8-40M-1NB1030A	EKL8-40M-1NB10100A	EKL8-40M-1NB10300A
		16A	EKL8-40M-1NB1630A	EKL8-40M-1NB16100A	EKL8-40M-1NB16300A
		20A	EKL8-40M-1NB2030A	EKL8-40M-1NB20100A	EKL8-40M-1NB20300A
		25A	EKL8-40M-1NB2530A	EKL8-40M-1NB25100A	EKL8-40M-1NB25300A
		32A	EKL8-40M-1NB3230A	EKL8-40M-1NB32100A	EKL8-40M-1NB32300A
		40A	EKL8-40M-1NB4030A	EKL8-40M-1NB40100A	EKL8-40M-1NB40300A
		Rated Current (A）	C Curve
			Sensitivity
			30mA	100mA	300mA
			Type AC
		6A	EKL8-40M-1NC0630	EKL8-40M-1NC06100	EKL8-40M-1NC06300
		10A	EKL8-40M-1NC1030	EKL8-40M-1NC10100	EKL8-40M-1NC10300
		16A	EKL8-40M-1NC1630	EKL8-40M-1NC16100	EKL8-40M-1NC16300
		20A	EKL8-40M-1NC2030	EKL8-40M-1NC20100	EKL8-40M-1NC20300
		25A	EKL8-40M-1NC2530	EKL8-40M-1NC25100	EKL8-40M-1NC25300
		32A	EKL8-40M-1NC3230	EKL8-40M-1NC32100	EKL8-40M-1NC32300
		40A	EKL8-40M-1NC4030	EKL8-40M-1NC40100	EKL8-40M-1NC40300
			Type A
		6A	EKL8-40M-1NC0630A	EKL8-40M-1NC06100A	EKL8-40M-1NC06300A
		10A	EKL8-40M-1NC1030A	EKL8-40M-1NC10100A	EKL8-40M-1NC10300A
		16A	EKL8-40M-1NC1630A	EKL8-40M-1NC16100A	EKL8-40M-1NC16300A
		20A	EKL8-40M-1NC2030A	EKL8-40M-1NC20100A	EKL8-40M-1NC20300A
		25A	EKL8-40M-1NC2530A	EKL8-40M-1NC25100A	EKL8-40M-1NC25300A
		32A	EKL8-40M-1NC3230A	EKL8-40M-1NC32100A	EKL8-40M-1NC32300A
		40A	EKL8-40M-1NC4030A	EKL8-40M-1NC40100A	EKL8-40M-1NC40300A

RCBO 6kA Magnetic Type Residual Current Operated Circuit Breaker

RCBO 6kA Magnetic Type Residual Current Operated Circuit Breaker

Porduct Overview

Technical parameters

Technical Data

Dimensions

Circuit Diagram

Installation size

Product selection form

Download Files

Porduct Overview

Technical parameters

Technical Data

Dimensions

Circuit Diagram

Installation size

Product selection form

Download Files
